7
ENGLISH
4. Tight the screw
12
holding the cinch collar firmly around
the neck of spindle (Fig. C2)
To Remove the Guard
1. Loosen the screw
12
holding the cinch collar around the
neck of thespindle.
2. Lift up on theguard.
Fitting and Removing a Grinding Disc
(Fig. A, D, E)

WARNING: Do not use a damageddisc.
1. Place the tool on a table, guardup.
2. Fit the backing flange
7
correctly onto the spindle
8
(Fig.D).
3. Place the disc
9
on the flange
7
. When fitting a disc with a
raised centre, make sure that the raised centre
10
is facing
the flange
7
.
4. Screw the outer flange
11
onto the spindle
8
(Fig.E). The
ring on the flange
11
must face towards the disc when
fitting a grindingdisc.
5. Press the spindle lock button
2
and rotate the spindle
8
until it locks inposition.
6. Tighten the flange
11
with the hex key provided or a two
pinspanner.
7. Release the spindlelock.
8. To remove the disc, loosen the flange
11
with the hex key
provided or a two pinspanner.
Prior to Operation
• Install the guard and appropriate disc or wheel. Do not use
excessively worn discs orwheels.
• Be sure the inner and outer flange are mountedcorrectly.
• Make sure the disc or wheel rotates in the direction of the
arrows on the accessory and thetool.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicableregulations.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. Be sure the
trigger switch is in the OFF position. An accidental start-up
can cause injury.

WARNING:
• Ensure all materials to be ground or cut are secured
inplace.
• Apply only a gentle pressure to the tool. Do not exert
side pressure on thedisc.
• Avoid overloading. Should the tool become hot, let it
run a few minutes under no loadcondition.
Proper Hand Position (Fig. A, F)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.

WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the side handle
4
,
with the other hand on the body of the tool, as shown in
FigureF.
Switching On and Off (Fig. A)

WARNING: Do not switch the tool on or off when
underload.

WARNING: Before using the tool, check that the handle is
tightenedsecurely.
To run the tool, press the switch
1
in before moving it
completelyforward.
To stop the tool, move the switch
1
back the oppositeway.
To stop the tool in continuous operation, press on the back part
of theswitch.
Spindle Lock (Fig. A)
The spindle lock
2
is provided to prevent the spindle from
rotating when installing or removing wheels. Operate the
spindle lock only when the tool is turned off, unplugged from
the power supply, and has come to a completestop.
NOTICE: To reduce the risk of damage to the tool, do
not engage the spindle lock while the tool is operating.
Damage to the tool will result and attached accessory
may spin off possibly resulting ininjury.
To engage the lock, depress the spindle lock button and rotate
the spindle until you are unable to rotate the spindlefurther.
Metal Applications
When using the tool in metal applications, make sure that a
residual current device (RCD) has been inserted to avoid residual
risks caused by metalswarf.
If the power supply is shut off by the RCD, take the tool to an
authorised DeWALT repairagent.

WARNING: In extreme working conditions, conductive
dust can accumulate inside the machine housing when
working with metal. This can result in the protective
insulation in the machine becoming degraded with a
potential risk of an electricalshock.
To avoid build-up of metal swarf inside the machine, we
recommend to clear the ventilation slots on a daily basis. Refer
toMaintenance.
Using Flap Discs

WARNING: Metal dust build-up. Extensive use of flap
discs in metal applications can result in the increased
potential for electric shock. To reduce this risk, insert an
RCD before use and clean the ventilation slots daily by
blowing dry compressed air into the ventilation slots
inaccordance with the below maintenanceinstructions.
