18
ENGLISH
• While “running in” DO NOT TIE, TAPE, OR OTHER WISE LOCK THE
TRIGGER SWITCH ON. HOLD BY HAND ONLY.
Lubrication
Your power tool requires no additional lubrication.
Cleaning
Before use, carefully check the upper guard, lower guard and dust duct
to determine that they will operate properly. Ensure that chips, dust or
workpiece particles do not block of one of the functions.
In case of workpiece fragments jammed between the saw blade and
guards, disconnect the machine from the power supply and follow the
instructions given in Changing or Installing a New Saw Blade. Remove
the jammed parts and reassemble the saw blade.
Periodically clean all dust and wood chips from around AND UNDER the
base and the rotary table.
WARNING: Blow dirt and dust out of the main housing with dry air
as often as dirt is seen collecting in and around the air vents. Wear
approved eye protection and approved dust mask when performing
this procedure.
WARNING: Never use solvents or other harsh chemicals for cleaning
the non-metallic parts of the tool. These chemicals may weaken the
materials used in these parts. Use a cloth dampened only with water
and mild soap. Never let any liquid get inside the tool; never immerse
any part of the tool into a liquid.
Worklight Cleaning
• Carefully clean sawdust and debris from worklight lens with a cotton
swab. Dust build-up can block the worklight and prevent it from
accurately indicating the line of cut.
• DO NOT use solvents of any kind; they may damage the lens.
• With blade removed from saw, clean pitch and build-up from blade.
Dust Duct Cleaning
With the saw unplugged and the saw head raised fully, low pressure air or a
large diameter dowel rod can be used to clear the dust out of the dust duct.
Optional Accessories (Fig. B–E)
WARNING: Since accessories, other than those offered by
,
have not been tested with this product, use of such accessories with
this tool could be hazardous. To reduce the risk of injury, only
recommended accessories should be used with this product.
Clamp: DE7082-XJ (Fig. B)
The clamp
35
is used for firmly clamping workpiece to the saw table.
Dust Bag: DE7053-XJ (Fig. C)
Equipped with a zipper for easy emptying, the dust bag
36
will capture the
majority of the sawdust produced.
Leg Stands: DE7023-XJ, DE7033-XJ (Fig. D)
The leg stand
37
is used to extend the table width of the saw.
Clamp Brackets: DE7025-XJ (Fig. E)
The clamp brackets
38
are used for mounting the saw to a stand.
SAW BLADES: ALWAYS USE 305 mm SAW BLADES WITH 30 mm ARBOUR
HOLES. SPEED RATING MUST BE AT LEAST 4800 RPM. Never use a smaller
diameter blade. It will not be guarded properly. Use crosscut blades only!
Do not use blades designed for ripping, combination blades or blades with
hook angles in excess of 5°.
BLADE DESCRIPTIONS
APPLICATION DIAMETER TEETH
Construction Saw Blades (thin kerf with anti-stick rim)
General Purpose 305 mm 40
Fine Crosscuts 305 mm 60
Woodworking Saw Blades (provide smooth, clean cuts)
Fine crosscuts 305 mm 80
Non-ferrous metals 305 mm 96
Consult your dealer for further information on the appropriate accessories.
Protecting the Environment
Separate collection. Products and batteries marked with this
symbol must not be disposed of with normal household waste.
Products and batteries contain materials that can be recovered or
recycled reducing the demand for raw materials. Please recycle
electrical products and batteries according to local provisions. Further
information is available at www.2helpU.com.
