DeWalt FLEXVOLT DCS520 User Manual

ENGLISH
1
English (original instructions)
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or property damage.

DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or seriousinjury.

WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or seriousinjury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderateinjury.

(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in propertydamage.

WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
seriousinjury.
WARNING: To reduce the risk of injury, read the
instructionmanual.
If you have any questions or comments about this or
any
DeWALT
tool, call us toll free at:
1-800-4-
DeWALT
(1-800-433-9258).
Fig. A1, A2
1
Plunge trigger
2
On/off switch
3
Main handle
4
Shoe
5
Rail adjustment knobs
6
Bevel scale
7
Bevel adjustment knob
8
Depth adjustment knob
9
Depth scale
10
Blade
Fig. A1
15
14
3
2
1
1312
10
11
8
9
6
7
16
4
5
5
11
Front handle
12
Spindle lock button
13
Spindle lock lever
14
Battery pack
15
Battery release button
16
Date code
17
Dust port
18
Anti-kickback knob
19
Speed wheel

DeWalt FLEXVOLT DCS520 Specifications

General

Brand	DeWalt
Model	FLEXVOLT DCS520
Category	Saw
Language	English
