ENGLISH
3
EC-Declaration of Conformity
Machinery Directive
Drill/Impact Drill
DCD800, DCD805
DeWALT declares that these products described under
Technical Data are in compliance with:
2006/42/EC, EN62841‑1:2015, EN62841‑2‑1:2018+A11:2019.
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact DeWALT at
the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf ofDeWALT.
Markus Rompel
Vice‑President Engineering, PTE‑Europe
DeWALT, Richard‑Klinger‑Straße 11,
65510, Idstein, Germany
30.10.2021
The vibration and/or noise emission level given in this
information sheet has been measured in accordance with
a standardised test given in EN62841 and may be used to
compare one tool with another. It may be used for a preliminary
assessment ofexposure.

WARNING: The declared vibration and/or noise emission
level represents the main applications of the tool. However
if the tool is used for different applications, with different
accessories or poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase
the exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/
or noise should also take into account the times when the
tool is switched off or when it is running but not actually
doing the job. This may significantly reduce the exposure
level over the total workingperiod.
Identify additional safety measures to protect the
operator from the effects of vibration and/or noise such
as: maintain the tool and the accessories, keep the
hands warm (relevant for vibration), organisation of
workpatterns.
DCD800 DCD805
Voltage
V
DC
18 18
Type
1 1
Battery type
Li‑Ion Li‑Ion
No‑load speed
1st gear min
‑1
0–650 0–650
2nd gear min
‑1
0–2000 0–2000
Impact rate
1st gear min
‑1
— 0–11050
2nd gear min
‑1
— 0–34000
Max. torque (hard/soft) Nm 90/27 90/27
Chuck capacity mm 1.5–13.0 1.5–13.0
Maximum drilling capacity
Wood mm 55 55
Metal mm 13 13
Masonry mm — 13
Weight (without battery pack) kg
1.28 1.34
Noise values and/or vibration values (triax vector sum) according to
EN62841‑2‑1:
L
PA
(emission sound pressure level) dB(A)
74 90
L
WA
(sound power level) dB(A)
85 101
K (uncertainty for the given sound level) dB(A)
5 5
Drilling into metal
Vibration emission value a
h,D
= m/s
2
< 2.5 < 2.5
Uncertainty K = m/s
2
1.5 1.5
Drilling into concrete
Vibration emission value a
h,ID
= m/s
2
— 11
Uncertainty K = m/s
2
— 1.5
Congratulations!
You have chosen a DeWALT tool. Years of experience, thorough
product development and innovation make DeWALT one of the
most reliable partners for professional power toolusers.
Technical Data
DRILL
DCD800
DRILL/HAMMERDRILL
DCD805
English (original instructions)
