DeWalt XR DCE800 User Manual

12
ENGLISH
Speed Control Dial (Fig.A)
The DCE800 sander is equipped with a variable speed control.
Adjust the speed by turning the speed control dial
4
. The speed
control dial is numbered “1” through “7”. The setting “1” is the
slowest speed (approximately 700 RPM) and “7” is the fastest
speed (approximately 1200RPM).
Use the higher speed settings for fast stock removal. Use
the lower speed setting to reduce removal rate for more
precisecontrol.
No-Volt
The No-volt function stops the sander from restarting without
the switch being cycled if there is a break in the powersupply.
Slider Switch (Fig.D)

CAUTION: Hold the main handle and body of the tool
firmly to maintain control of the tool at start up and
during use and until the wheel or accessory stops rotating.
Make sure the wheel has come to a complete stop be fore
laying the tooldown.
NOTE: To reduce unexpected tool movement, do not switch
the tool on or off while under load conditions. Allow the sander
to run up to full speed before touching the work surface. Lift the
tool from the surface before turning the tool off. Allow the tool
to stop rotating before putting itdown.

WARNING: Before connecting the tool to a power supply,
be sure the slider switch is in the off position by pressing
the rear part of the switch and releasing. Ensure the
slider switch is in the off position as described above after
any interruption in power supply to the tool, such as a
deadbattery.
To start the tool, slide the ON/OFF slider switch
3
toward
the front of the tool. To stop the tool, release the ON/OFF
sliderswitch.
For continuous operation, slide the switch toward the front of
the tool and press the forward part of the switch inward. To stop
the tool while operating in continuous mode, press the rear part
of the slider switch andrelease.
Inserting and Removing the Battery Pack
from the Tool (Fig. B)
NOTE: Make sure your battery pack
1
is fullycharged.
To Install the Battery Pack into the Tool Handle
1. Align the battery pack
1
with the rails inside the tool’s
handle (Fig. B).
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap intoplace.
To Remove the Battery Pack from the Tool
1. Press the release button
2
and firmly pull the battery pack
out of the toolhandle.
2. Insert battery pack into the charger as described in the
charger section of thismanual.
Fuel Gauge Battery Packs (Fig. B)
Some
DeWALT
battery packs include a fuel gauge which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge
button
16
. A combination of the three green LED lights will
illuminate designating the level of charge left. When the level
of charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-userapplication.
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.

WARNING: Use only
DeWALT
battery packs andchargers.
8
Tube expansion lever
9
Sanding pad
Intended Use
This drywall sander is designed for professional
sandingapplications.
Do not use under wet conditions or in the presence of
flammable liquids orgases.
This drywall sander is a professional powertool.
Do not let children come into contact with the tool. Supervision
is required when inexperienced operators use thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
Attaching Sanding Discs (Fig.C)
Your DCE800 drywall sander is designed to use 225 mm sanding
discs
11
. Sanding discs for the DCE800 attach with hook
andloop.
The recommended sanding discs are available at extra cost from
your local dealer or authorised
DeWALT
servicecentre.
To Attach Sanding Disc to the Sanding Pad
(Fig.C)
1. Turn the sander over so that the sanding pad
9
is
facingupward.
2. Clean the dust from the sanding padface.
3. Hold the pad with one hand to keep it fromrotating.
4. With the other hand, center and place the sanding disc
11
directly on top of thepad.
