DeWalt XR Li-Ion DCB1106 User Manual

2
ENGLISH
Congratulations!
You have chosen a DeWALT tool. Years of experience, thorough product development and innovation make DeWALT one of the
most reliable partners for professional power toolusers.
Technical Data
DCB1106 DCB1106-TW DCB117 DCB1112-TW
Output V
DC
10.8, 18(12,20 Max) 10.8, 18(12,20 Max) 18 (20 Max) 18 (20 Max)
Mains voltage V
AC
220-240 110 220-240 110
Battery type Li-Ion Li-Ion Li-Ion Li-Ion
Charger current
Input A 1.5 2.5 1.5 6
Output A 6 6 12 12
Weight (without battery pack) kg 0.7 0.7 0.9 0.9
English (original instructions)
BATTERY CHARGER
DCB1106, DCB117, DCB1112
Batteries
Chargers/Charge Times (Minutes)
Cat #
DC
Weight
*Date code 201811475B or later
**Date code 201536 or later
Batteries Chargers/Charge Times (Minutes)
Cat # V
DC
Ah Weight(kg)
DCB104 DCB107 DCB112 DCB113 DCB115 DCB1106 DCB117 DCB1112 DCB118 DCB132 DCB119
DCB546/DCB606 18/54 (20/60 Max) 6.0/2.0 1.05 60 270 170 140 90 80 40 40 60 90 X
DCB547/DCB609 18/54 (20/60 Max) 9.0/3.0 1.46 75 420 270 220 135 110 60 60 75 135 X
DCB548/DCB612 18/54 (20/60 Max) 12.0/4.0 1.44 120 540 350 300 180 150 80 80 120 180 X
DCB181 18 (20 Max) 1.5 0.35 22 70 45 35 22 22 22 22 22 22 45
DCB182/DCB204 18(20 Max) 4.0 0.61 60/40 185 120 100 60 60/45 60/40 60/40 60/40 60 120
DCB183/DCB203 18(20 Max) 2.0 0.40 30 90 60 50 30 30 30 30 30 30 60
DCB184/DCB205 18(20 Max) 5.0 0.62 75/50 240 150 120 75 75/60 75/50 75/50 75/50 75 150
DCB185 18(20 Max) 1.3 0.35 22 60 40 30 22 22 22 22 22 22 X
DCB187 18(20 Max) 3.0 0.54 45 140 90 70 45 45 45 45 45 45 90
DCB189 18(20 Max) 4.0 0.54 60 185 120 100 60 60 60 60 60 60 120
DCB122 10.8(12 Max) 2.0 0.22 30 90 60 50 30 30 X X X 30 60
DCB124 10.8(12 Max) 3.0 0.25 45 140 90 70 45 45 X X X 45 90
DCB125 10.8(12 Max) 1.3 0.20 22 60 40 30 22 22 X X X 22 40
DCB127 10.8(12 Max) 2.0 0.20 30 90 60 50 30 30 X X X 30 60
WARNING: To reduce the risk of injury, read the
instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.

DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.

WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.

CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result in
propertydamage.

Denotes risk of electricshock.

Denotes risk offire.

DeWalt XR Li-Ion DCB1106 Specifications

General

Brand	DeWalt
Model	XR Li-Ion DCB1106
Category	Battery Charger
Language	English
