Installation C35F, C55F, C75F
18
6 Installation
6.1 Selecting the installation location
Observe the following, when selecting the installation location:
• The ambient temperature should be in accordance with the climate class. Other-
wise, it is possible that the inner temperature you set cannot be reached or main-
tained. This could also be the case if there are extreme fluctuations in the ambient
temperature.
The intended ambient temperature use and the climate class can be found in the
technical data (see chapter “Technical data” on page 26) and on the data plate,
which is located at the left on the inside of the wine cooler.
• The ground must be level and sufficiently stable to support the wine cooler at full
capacity.
• The wine cooler must be positioned so that the plug is accessible.
• Note the information on the electrical connection, see chapter “Connecting the
wine cooler” on page 19.
➤ Remove all the inner and outer packaging material before setting up.
6.2 Integrating free-standing wine coolers
The wine cooler can be integrated either under a countertop or between other cab-
inets.
Observe the following, when integrating the wine cooler:
• Observe the installation dimensions (fig. 3, page 4).
• Ensure the door will open and close properly in the chosen location.
• Waste heat produced by the wine cooler must be extracted via ventilation open-
ings on the rear and at both sides.
6.3 Adjusting the feet
➤ Make sure the wine cooler is level by adjusting the feet (fig. 4 , page 5).
