3.4 Description of components
Removable cover and seat
Toilet bowl
Emptying blade for the toilet bowl
Fresh water tank (capacity depends on the model)
Level indicator / flush (control panel)
Cassette tank (capacity 19 l)
Pour out spout
Vent button for emptying
Service door
Pull-out handle (cassette tank movable on wheels)
2
1
3
4
5
6
7
8
9
10
9
Description of model
Fig. 3
2
4
3
6
3
8
7
9
10
1
5
7
10
