Dometic MasterFlush 7120 User Manual

5
4 Components
Installed toilet (g.
1
, page 2)
Toilet components (g.
2
, page 2)
5.2 Minimum System Requirements
5 Specifications
5.1 Materials
Toilet: vitreous ceramic
Toilet base: polypropylene
Dometic flush switch panel: polystyrene (DFS-1F or DFS-2F); or powder-coated aluminum
(DFST)
Electrical
Power draw 20amps/12VDC;10amps/24VDC
Circuit breaker 25amps/12VDC;15amps/24VDC
Wiring
12ga.(upto25ft./7.6mtotalcircuit)
Consult ABYC guidelines for additional information.
Water
Supply
Fitting size
Supply hose ID
0.5in.NPT–freshwaterushtoilet
0.75in.ID–rawwaterushtoilet
Flow rate 2.0gpm/7.6lpmminimum–freshwaterush
Discharge
Inside diameter 1.5in./38mmor1in./25mm
Horizontal run* 40ft./12.2mmaximum
Vertical run* 4ft./1.2mmaximum
*Horizontalandverticalrundistancesarenotcumulative.Checkforadequatedischargeow
if installation nears one of these limits.
Specications are subject to change without notice.
Ref. Description
A Macerator toilet
B1 DFS-2Fushswitch(standard-
freshwaterushtoilet)
B2 DFS-1Fushswitch(standard-
rawwaterushtoilet)
NS DFSTushswitch(optional)
NOT SHOWN - see page 6
Ref. Description
1 Rimushcheckvalve(freshwater
toilet) or adapter (raw water model)
2 Water supply hose
3 Macerator pump
(under plastic cover)
4 Electric water valve
5 Product ID label location
6 Stainless steel compression band
7 Discharge tting
Refer to complete parts list (packed separately)
for additional information.
