Operating the awning PW1000, PW1500, PW1750
18
7Operating the awning
Observe the safety instructions in chapter “Safety instructions” on page 13.
7.1 Note on the vehicle location
A
7. 2 E x te n d i n g t h e aw n i n g
Extending the awning using a hand crank
!
➤ Click the hand crank into the holder in the awning (fig. 2, page 3).
➤ Turn the hand crank until the awning is extended by about 1.5 metres (fig. 3,
page 4).
➤ Push the right strut in the front cover together so that you can move it freely
(fig. 5, page 5).
➤ Turn the right strut to the side (fig. 5, page 5).
➤ Fold the right strut down and set it on the ground (fig. 6, page 5).
➤ Adjust the strut to the required height (fig. 7, page 6).
➤ Fold the lever for the strut up to secure the struts (fig. 8, page 6).
➤ Extend the other strut in the same way.
➤ Turn the hand crank until the awning is extended to the required position.
Position the struts vertically and back under the lead rail every 30 cm so that the
awning stays secured at all times.
➤ Turn the hand crank approx. a quarter of the way back to tighten the fabric.
NOTICE!
• Park the vehicle so that no debris (branches, leaves or similar) gets on
to the fabric.
• Keep the awning free of dirt to prevent abrasions, stains and mildew.
WARNING! Beware of injury.
Keep a sufficient distance from objects or other vehicles. Once it is
retracted, it should be at least 40 cm away from other objects and
vehicles on all sides.
PW1000-PW1500-PW1750-O-16S.book Seite 18 Donnerstag, 5. Oktober 2017 11:05 11
