18
Refrigerator operation
Fig. 18
Fig. 17
Fasten Release
If the vehicle is parked for a longer period of
time, the locking hook can be clamped by
means of a locking bar (s. Fig. 17-18).
The door can be opened by pulling it.
4.5.2 Fastening and releasing the door
lock hook when parking the
vehicle
4.6 Positioning the storage racks
If it is necessary to remove these storage
racks (1) yet (i.e. for cleaning), first loosen the
locking pins (2) as shown with a suitable
screwdriver ( s. Fig. 19 - 20). The storage
racks may be pulled out by loosening the two
locking devices (3) underneath. For loosening
pull the slider to the middle, for fastening pull
them sidewards.
The central storage racks (1) are secured. In
this way inadvertent entrappment and suffo-
cation of children is prevented, if the storage
racks are removed. To protect children it must
be avoided to create space for children in the
cooling compartment.
Remove the central storage racks for
cleaning only! Place and lock the storage
racks at the same place afterwards.
Thus children have no space to be
entrapped in the refrigerator.
WARNING!
Put in place the locking pins (2) after removing
the storage racks.
i
Fig. 20
Fig. 19
Bottom side
Fig. 21
3
3
1
3
3
2
1
2
1.
2.
