7
Measuring instrument
1Display
2Menu button "UP"
3"OK" button
4Menu button "DOWN/MENU"
5Socket
6Lamp red/green
7Mouthpiece receptacle
Mittauslaite
1Näyttöruutu
2Valikkonäppäin "YLÖS"
3"OK"-näppäin
4Valikkonäppäin "ALAS/VALIKKO"
5Huoltoliitin
6Merkkivalo punainen/vihreä
7Suukappaleen liitäntä
00223757_1.eps
OK
Alcotest 6510
M
1
2
3
4
6
7
5
