Technical data
Dräger X-dock 5300/6300/6600 33
9 Technical data 10 Order list
Dimensions (H x W x D):
Master approx. 3.54 x 5.70 x 9.84 inches
(120 x 130 x 250 mm)
Pac / X-am 125
module
approx. 3.54 x 5.70 x 9.84 inches
(90x145x250mm)
X-am 8000 module 122 x 145 x 250 mm
Weight:
Master
approx. 4.02 pounds (48.23 ounces;
1500 g)
Pac / X-am 125
module
approx. 2.57 pounds (30.86 ounces;
960 g)
X-am 8000 module approx. 1225 g
X-am 8000+ module approx. 1445 g
Ambient conditions:
During operation
During storage
32 °F to +104 °F (0 °C to +40 °C)
-4 °F to +122 °F (-20 °C to +50 °C)
700 to 1300 hPa
max. 95 % relative humidity
During charging
(X-am 8000+ module
only)
0 °C to +35 °C (outside of this
temperature range charging is possible
only to a limited extent)
Gas connections: 1x fresh air connection
1x compressed air inlet
1x exhaust outlet
X-dock 5300/6300 3x gas inlets
X-dock 6600 6x gas inlets
Inlet pressure:
for the measured gas 0.5 bar ±20 %
for compressed air 0.5 bar ±20 %
Power supply: 11 V - 28 V DC, 6.25 A
Connections: 3x USB 2.0 standard A connection,
(host, cable <3 m)
1x USB 2.0 mini-B connection,
(device, cable <3 m)
1x Ethernet port RJ45
Data rate10/100 Mbit
Serial no. (year of
manufacture):
The year of manufacture is the 3rd
Letters contained in the factory number
shown on the name plate: H=2015,
J=2016, K=2017, L=2018 M=2019, etc.
Example: Serial number ARKH-0054,
the 3rd letter is K, i.e. the year of
manufacture is 2017.
CE mark: Electromagnetic compatibility
(Directive 2004/108/EC)
Name and description
Order No.
Dräger X-dock 5300 X-am 125 83 21 880
Dräger X-dock 5300 Pac 83 21 881
Dräger X-dock 5300 X-am 8000 83 21 882
Dräger X-dock 6300 Master 83 21 900
Dräger X-dock 6600 Master 83 21 901
Dräger X-dock Module X-am 125 83 21 890
Dräger X-dock Module X-am 125+
(with charge function)
83 21 891
Dräger X-dock Module X-am 8000 83 21 893
Dräger X-dock Module X-am 8000+
(with charge function)
83 21 894
Dräger X-dock Module Pac 83 21 892
Single wall mount 83 21 922
Comfort wall mount 83 21 910
Cylinder holder (table-top version) 83 21 918
Cylinder holder for top-hat rail 83 21 928
Power pack 24 V / 1.33 A (up to 3 modules) 83 21 849
Power pack 24 V / 6.25 A (up to 10 modules) 83 21 850
X-dock car adapter 83 21 855
Pressure regulator valve 0.5 bar (nickel-
plated)
83 24 250
Pressure regulator valve 0,5 bar, Flowstop 83 24 251
Pressure regulator valve 0.5 bar (stainless
steel)
83 24 252
Hose clamp, 5 pce. 83 24 095
Pump filter set (includes filter and hose
connector)
83 19 364
Fluorinated rubber hose 12 03 150
Sealing insert (X-am 125) 83 21 986
Sealing insert (Pac) 83 21 987
Sealing insert (X-am 8000) 83 26 543
Hose coupling (X-am 8000) 83 26 544
X-dock Master display protector film 83 21 804
Stickers for module numbering 83 21 839
Barcode label, exterior
(22 x 8 mm, 500 labels)
AG02551
Barcode scanner 83 18 792
Dräger X-dock Manager Basic 83 21 860
Dräger X-dock Manager Professional 83 21 870
Dräger X-dock Manager Licence
(1x, both versions)
83 21 857
Dräger X-dock Manager Licence
(5x, both versions)
83 21 858
