Ducati 996 User Manual

39
E
1
Headlamp fairing
Undo the middle fastening screw (1, fig. 26.1) of the
wing mirrors and remove them from the headlamp fairing
supports.
Undo the two fastening screws (2) of the headlight
support and disconnect the four connectors (3) joining
the two body panels together.
Important
At reassembly, apply “medium-strength
threadlocker” onto the screw threading (1).
fig. 26.1
fig. 26.2
3
2

Ducati 996 Specifications

General

Displacement	996 cc
Compression ratio	11.5:1
Fuel System	Electronic fuel injection
Transmission	6-speed
Frame	Tubular steel trellis
Front suspension	Showa upside-down fork, fully adjustable
Rear suspension	Showa monoshock, fully adjustable
Seat Height	790 mm (31.1 in)
Engine type	L-twin, 4-valve per cylinder, desmodromic, liquid-cooled
Bore x Stroke	98 mm x 66 mm
Front brakes	2 x 320 mm discs, 4-piston calipers
Rear brakes	Single 220 mm disc, 2-piston caliper
Fuel capacity	17 L (4.5 US gal)
Wheelbase	1410 mm
Power	112 hp @ 8500 rpm
Dry weight	198 kg
