Ducati 996 User Manual

67
E
Legend of fuse box (4)
Pos. Description Rat.
A-1 Main switch 30 A
B-2 Cooling electric fan 7.5 A
C-3 Left switch 3 A
D-3 High beam 15 A
E-5 Low beam 15 A
F-6 Turn indicators, warning lights, 7.5 A
tail lights and instrument panel
lights
G-7 Stop, warning horn 7.5 A
H-8 Right switch 3 A
Note
The electric system wiring diagram is at the end of
this manual.
Wire color coding
W-Y White-Yellow
P Pink
GR-Bk Grey-Black
Y-G Yellow-Green
G Green
R-G Red-Green
W-R White-Red
O-Bk Orange-Black
V-Bk Violet-Black
Y Yellow
W-B White-Blue
BN Brown
G-W Green-White
O-W Orange-White
R-Bk Red-Black
R-B Red-Blue
GR-R Grey-Red
R Red
G-Bk Green-Black
V Violet
Y-Bk Yellow-Black
GR Grey
G-B Green-Blue
Lb Light blue
Bk Black

Ducati 996 Specifications

General

Displacement	996 cc
Compression ratio	11.5:1
Fuel System	Electronic fuel injection
Transmission	6-speed
Frame	Tubular steel trellis
Front suspension	Showa upside-down fork, fully adjustable
Rear suspension	Showa monoshock, fully adjustable
Seat Height	790 mm (31.1 in)
Engine type	L-twin, 4-valve per cylinder, desmodromic, liquid-cooled
Bore x Stroke	98 mm x 66 mm
Front brakes	2 x 320 mm discs, 4-piston calipers
Rear brakes	Single 220 mm disc, 2-piston caliper
Fuel capacity	17 L (4.5 US gal)
Wheelbase	1410 mm
Power	112 hp @ 8500 rpm
Dry weight	198 kg
