Chapter 3
The Grand Tour
This chapter identifies the various components of the computer. It is
recommended that you become familiar with each before you operate the
computer.
Legal Footnote (Non-applicable Icons)
For more information regarding Non-applicable Icons, refer to the Legal
Footnotes section.
Handle your computer carefully to avoid scratching or damaging the
surface.
Front with the display closed
The following figure shows the front of the computer with the display panel
in the closed position.
Figure 3-1 Front of the computer with display panel closed
Left side
The following figure shows the left side of the computer.
Figure 3-2 The left side of the computer
1. DC IN/Battery indicator 4. Universal Serial Bus (USB 3.2 Gen1)
port
2. DC IN 19V jack 5. USB Type-C™ (USB 3.2 Gen1) port
3. HDMI™ out port
Product appearance depends on the model you purchased.
User's Manual 3-1
