E-Wheels EW-36 User Manual

4
Mirror Assembly
Your power scooter is shipped partially disassembled for protection during shipping. After unpacking,
please check whether you have received the following main components as our standard specification
(See Fig 1)
1. Mirrors
Mirror Post
Fig 1
To attach the mirrors simply place each mirror threaded end into the mirror post. Turn mirror clockwise
and fasten mirror to scooter.
Operation of Scooter:
1. To prevent injury to yourself or others, always ensure that the power is switched off when getting
on or off the scooter.
2. Always check that the variable speed control is set to the desired speed setting.

E-Wheels EW-36 Specifications

General

Speed:	Up to 15mph
Distance:	43 miles per charge (distance varies on terrain, riders weight and road surface etc.)
Turning Radius:	50”
High/ Low Speed switch:	Adjustable Speed Knob / Rheo-Stat
Throttle Type:	Variable Speed Control – Twist throttle
Braking System:	Front and Rear drum brakes
Drive System:	500 Watt Brushless Motor
Front Seat: Type	Adjustable Folding Captains chair with backrest
Front Seat:	41” From Ground
Rear Foot Rest:	N/A
Forward/Reverse switch:	Yes
Key Start:	Yes
Power:	Electric
Watts:	500 Watt
Amps:	20 AH
Volts:	48 Volts
Charger:	48-volt Smart Charger included
Motor Type:	Transaxle differential brushless
Front Basket:	None
Batteries:	(4) Sealed Lead Acid Maintenance Free
Battery Indicator:	Yes
Headlight:	56v Bulb
Rear lights:	56V bulb
Reflectors:	N/A
Front:	Front Shock Absorbers
Rear:	Rear Shock Absorbers
Warranty:	Limited – 3 Year Warranty

Weight and Dimensions

Weight Capacity	350Lbs.
Front seat: Size	18 ¼” x 18 ¼” x 34” (LxWxH)
Basket Dimensions:	10”x17”x9” (LxWxH)
Steering Height	40” from Ground
Dimensions:	61” x 27” x 53 ½” (LxWxH)
Floor Clearance:	5”
Front tire size:	15” x 3.5”
Rear tire size:	15” x 3.5”
Carton Size:	Shipped Fully assembled on Pallet – 63”x36”x54” (LxWxH)
Scooter Weight:	219lbs. with batteries
