Specifications
Eaton 1250W / 1500W / 1800W Inverter Operation and Installation Guide IM SP180164 / Rev D www.eaton.com
Specifications
Appendix A is the location for product performance information and electrical specifications for the 1800W Eaton Inverter.
Important: Specs are subject to changes without notice.
Technical specifications
Table 8. Input Voltages
Low Mid High
Nominal DC input
12.5Vdc 13.0Vdc 13.0Vdc
Input voltage operating range 10.5-16.0Vdc 11.8-16.0Vdc 12.2-16.0Vdc
No load input current (inverter on)
< 0.9Adc when input voltage is ≥ 11.5Vdc
< 1.5Adc when input voltage is < 11.5Vdc
No load input current (inverter off) < 1.0mA (inverter button off and no utility power connection
All DC voltage tolerances +/- 0.3Vdc
Table 9. AC Outputs
1800W
Continuous output power
1800W (15A)
Surge output power (5 seconds) 2000W
Surge output power 3600W (300ms)
Operating temperature range 0°C to +50°C
Storage temperature range -40°C to 85°C
THD (Resistive load) 5% max, 2.5% typical
Output power rated at 25°C, continuous power de-rated linearly to 70% at 50°C. After extreme hot or cold storage, unit requires one hour of 0°C to 25°C storage before
operating.
Table 10. AC Transfer
AC input transfer from utility to
inverter
95Vac
AC input recovery from inverter to
utility
100Vac
Utility to inverter and inverter to
utility hysteresis
5Vac minimum
Max AC output by-pass current 20 Arms
AC transfer time - utility to inverter < 50ms
Time delay on transfer from
inverter to utility
20s +/- 2s
Voltages +/- 5V
Table 11. Battery Charger
AC input operating range
95-135Vac
AC input range with full power 105-135Vac
AC input current with no load <0.50 Arms
Input current full load 11.5 Arms
AC input frequency 60Hz +/- 1Hz
Operating temperature range 0°C to +50°C (allow for 1.5Adc charge current reduction above 40°C)
