Table9. Function menu (continued)
Level 1
Main Menu
Level 2
Sub-Menu
Level 3
Sub-Menu
Level 4
Sub-Menu Parameter
Function
Code
*SETTINGS (Cont.) *Calendar/Clock System Calendar and Clock 050
UTC Time Zone 050
Date Format 942
Time Format 943
_Multi-Phase Config Multi-Phase Feature 200
Multi-Phase Mode 201
Multi-Phase VRs Configured 202
Multi-Phase Lead Regulator 203
VR1 Tap Wait Timer 204
VR2 Tap Wait Timer 204
VR3 Tap Wait Timer 204
Multi-Phase Retry Count 205
Multi-Phase Retry Delay 206
Multi-Phase Total Deviation 207
Timer To Max Deviation Mode 208
Timer To Alt Mode 209
Max Deviation Alt Mode 210
Sequencing Interval 211
Multi-Phase DeltaCalc Mode 212
*FEATURES *Auto-Block Status Auto Operation Blocking Status 069
Block Before Remote Tap 169
*Reverse Power Mode Reverse Sensing Mode 056
Reverse Current Sense Threshold 057
Bias Co-Gen Alt Mode 058
*Source Side Voltage Calc Source Voltage Calculation 039
*Voltage Limiter Voltage Limiter Mode 080
High Voltage Limit 081
Low Voltage Limit 082
Voltage Limiter Fast Resp. Delay 083
Voltage Limiter Delay 084
Time Between Taps 085
*Voltage Reduction Voltage Reduction Mode 070
Reduction In Effect 071
Local/Digital Reduction Value 072
Remote #1 Value 073
Remote #2 Value 074
Remote #3 Value 075
# of Pulse Reduction Steps 076
% of Voltage Red Per Pulse Step 077
Present Voltage Reduction Step 078
32
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018
CL-7 Voltage Regulator Control
