Table10. Function codes (continued)
Parameter
Unit of
Measure
Security Level
Default Value
Key Entry Limit
To Read To Write To Reset Low High
036 Reverse
kvar Load High
XXXX.X kvar
MM-DD-YYYY HH:MM:SS
kvar View NA Operate Reset* NA NA
•This is the highest value of the load kvar during reverse power flow since last reset, as
a demand value, according to the demand time interval at FC 46.
•Date and time of the occurrence of the highest kvar load is displayed.
•The control requires source voltage from a differential or source potential transformer or
from the source voltage calculation (see FC 39) to obtain this parameter. Lack of this
voltage will result in the parameter displaying dashes.
036 Reverse
kvar Load Low
XXXX.X kvar
MM-DD-YYYY HH:MM:SS
kvar View NA Operate Reset* NA NA
•This is the lowest value of the load kvar during reverse power flow since last reset, as
a demand value, according to the demand time interval at FC 46.
•Date and time of the occurrence of the lowest kvar load is displayed.
•The control requires source voltage from a differential or source potential transformer or
from the source voltage calculation (see FC 39) to obtain this parameter. Lack of this
voltage will result in the parameter displaying dashes.
036 Reverse kvar
Load Present
XXXX.X kvar
kvar View NA NA NA NA NA
•This is the present value of the load kvar during reverse power flow, as a demand value,
according to the demand time interval at FC 46.
•The control requires source voltage from a differential or source potential transformer or
from the source voltage calculation (see FC 39) to obtain this parameter. Lack of this
voltage will result in the parameter displaying dashes.
037 Reverse Source
Voltage High
XXX.X Volts
MM-DD-YYYY HH:MM:SS
Volts View NA Operate Reset* NA NA
•This is the highest value of the primary input voltage of the regulator during reverse
power flow since last reset, as a demand value, according to the demand time interval at
FC 46.
•Date and time of the occurrence of the highest source voltage is displayed.
037 Reverse Source
Voltage Low
XXX.X Volts
MM-DD-YYYY HH:MM:SS
Volts View NA Operate Reset* NA NA
•This is the lowest value of the primary input voltage of the regulator during reverse
power flow since last reset, as a demand value, according to the demand time interval at
FC 46.
•Date and time of the occurrence of the lowest source voltage is displayed.
037 Reverse Source
Voltage Present
XXX.X Volts
Volts View NA NA NA NA NA
•This is the present value of the primary input voltage of the regulator during reverse
power flow, as a demand value, according to the demand time interval at FC 46.
59
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018
CL-7 Voltage Regulator Control
