Table10. Function codes (continued)
Parameter
Unit of
Measure
Security Level
Default Value
Key Entry Limit
To Read To Write To Reset Low High
•When a battery is connected to the control, this will display the voltage and current
readings of the battery found while running the battery test routine.
192 Automatic
Test Battery
Disabled
--- View Modify NA Disabled NA NA
•When enabled, a battery test will automatically be run within 60 seconds of power-up and
then 12 hours after the last battery test. The options are: Disabled; Enabled.
194 Factory Default --- NA NA Admin NA NA NA
•This feature will reset all control settings, parameters, data, and metering information
back to the factory default.
•The reset includes passwords.
•This parameter is not found in the nested menu, and can only be found using the function
code.
199 Remote Security
Override Timer
XX Hours
Hours View Admin NA 0 0 24
•This parameter is the time that the security override will be active once enabled.
199 Remote Security
Override Mode
Disabled
--- View View NA Disabled NA NA
•The security level can be temporarily overridden remotely. This parameter is used to
enable or disable the feature. The options are: Disable; Enable.
200 Multi-phase
Feature
Off
--- View Modify NA Off NA NA
•Enables the control for multi-phase operation. The options are: Off; On.
201 Multi-phase
Mode
Independent
--- View Modify NA Independ. NA NA
•Sets the mode of multi-phase operation on the control when the multi-phase mode has been
turned on. Options are: Independent; Lead Phase Reg.; Voltage Averaging; Max Deviation
Advanced Independent.
•See Section 6: Control Features: Multi-phase voltage regulation for more information.
202 Multi-phase
VRs Configured
X
--- View Modify NA 2 2 3
•The number of voltage regulators configured for multi-phase operation. The available
settings are 2 and 3.
203 Multi-phase
Lead Regulator
VR1
--- View Modify NA VR1 NA NA
•Assigns the lead regulator for certain multi-phase operation modes. The available
settings are: VR1; VR2; VR3.
•See Section 6: Control Features: Multi-phase voltage regulation for more information.
204 VR1 Tap Wait
Timer
XXXXX mSec
MilliSec View Modify NA 0 0 10000
80
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018
CL-7 Voltage Regulator Control
