Eaton 350 Series User Manual

9EATON Dual Path Mobile Pump E-PUPI-TM005-E2 September 2007
197.8
[7.79]
26.0
[1.02]
26.0
[1.02]
Drain Port - D2
(Location and
Plug Optional)
Pressure
Port -A1
77.4
[3.05]
160.5
[6.32]
312.4
[12.30]
431.7
[16.99]
Pressure
Port - B1
Drain Port -D4
(Location and Plug Optional)
Auxiliary Port -C6
(Location and Plug Optional)
10.5
[0.41]
15.0
[0.59]
20.0
[0.79]
ø101.68±0.03
[4.003±0.001]
This Groove to
Accept an
ARP 045 (1/16 x 4 ID)
O-Ring
4x 1/2-13 UNC-2B
19.6[.77]
Min Full Thread
2x 87.0
[3.43]
Drain Port
114.0
[4.49]
Pressure Ports
2x 87.0
[3.43]
Drain Port
100.0
[3.94]
-C6 Port
100.0
[3.94]
-C5 Port
146.0
[5.75]
Dimensional
Drawings -
Solenoid
Displacement
Control
350 Series Dual Pump, Solenoid displacement control,
SAE C mounting flange, 14-tooth, 12/24 pitch spline, SAE B
Aux mount with charge pump, opposite side ports.
Solenoid Displacement Control
SPECIFICATIONS
3 ways proportional reducing pressure valve
Hysteresis max 2.5 bar
Pressure drop 10 bar for 10 L/min
Leakages (P.A. T)
Without electric supply < 8 cc/min
(P
supply
= 60 bar, fluid viscosity 11 cSt)
During regulation (P
controll
= 25 bar) < 30 cc/min
Response time 0-60 bar < 20ms
60-0 bar < 20ms
Frequency response from 0.3 to 35Hz Pressure gain +/- 3 dB
Frequency phase < -90˚C
Maximum control current 2.4A
Supply current Dither 100Hz
Coil resistance 2.5 Ohm
Dimensions are in mm(in) unless noted otherwise.
