The following table describes typical conditions:
Conditions Possible cause Action
Battery mode
LED is On.
1 beep every 10 seconds
A utility failure has occurred and the UPS is in
battery mode.
The UPS is powering the
equipment with battery power.
Prepare your equipment for
shutdown.
Battery mode
LED is On.
1 beep every 3 seconds
The UPS is in Battery mode and the battery is
running low.
This warning is approximate, and
the actual time to shutdown may
vary significantly. Depending on
the UPS load and number of
Extended Battery Modules (EBMs),
the "Battery Low" warning may
occur before the batteries reach
20% capacity.
No battery
LED is On
Beep continuous
The batteries are disconnected.
Verify that all batteries are
properly connected. If the
condition persists, contact your
service representative.
Battery mode
LED is On.
Beep continuous
The battery test is failed due to bad or
disconnected batteries.
Verify that all batteries are
properly connected. If the
condition persists, contact your
service representative.
The UPS does not provide the
expected backup time.
The batteries need charging or service.
Apply utility power for 48 hours to
charge the batteries. If the
condition persists, contact your
service representative.
Power Overload
LED is On
Power requirements exceed the UPS capacity
(greater than 100% of nominal;
see “User Settings” for specific output overload
ranges).
Remove some of the equipment
from the UPS. The UPS continues
to operate, but may shut down if
the load increases. The alarm
resets when the condition
becomes inactive.
UPS Over temperature
LED is On
1 beep every 3 seconds
The UPS internal temperature is too high or a fan
has failed. At the warning level, the UPS
generates the alarm but remains in the current
operating state. If the temperature rises another
10°C, the UPS shuts down.
Clear vents and remove any heat
sources. Allow the UPS to cool.
Ensure the airflow around the UPS
is not restricted. Restart the UPS. If
the condition continues to persist,
contact your service
representative.
The UPS does not start
The input source is not connected correctly.
Check the input and battery
connections.

Eaton 5PX Specifications

General

Output Voltage	230V
Topology	Line-Interactive
Efficiency	Up to 99%
LCD Display	Yes
Typical Recharge Time	3 hours to 90%
Operating Temperature	0°C to 40°C
Form Factor	Tower
Battery Type	Sealed, lead-acid
Communication Ports	USB, Serial
Output Frequency	50/60 Hz
Input Voltage Range	160-294V
Storage Temperature	-15°C to 45°C
Relative Humidity	0% to 95% non-condensing
Audible Noise	<45 dB at 1 meter
Dimensions (HxWxD)	Varies by model
Weight	24 kg
