Introduction
Eaton's Cooper Power™ series 600 A, 15, 25, and 35 kV
Class PUSH-OP™ deadbreak connector offers a complete
threadless deadbreak, hotstick operable connection system
for terminating underground cables to transformers,
switches, switchgear, and other apparatus. It is fully
shielded, submersible, and meets the requirements of IEEE
Std 386™-2006 standard - Separable Insulated Connector
Systems. Service Information MN650011EN provides
operation instructions.
Read this manual first
Read and understand the contents of this manual and follow
all locally approved procedures and safety practices before
installing or operating this equipment.
Additional information
These instructions cannot cover all details or variations
in the equipment, procedures, or process described nor
provide directions for meeting every possible contingency
during installation, operation, or maintenance. For additional
information, contact your Eaton representative.
Acceptance and initial inspection
Each PUSH-OP connector is in good condition when
accepted by the carrier for shipment. Upon receipt, inspect
the shipping container for signs of damage. Unpack the
PUSH-OP connector and inspect it thoroughly for damage
incurred during shipment. If damage is discovered, file a
claim with the carrier immediately.
Handling and storage
Be careful during handling and storage of the PUSH-OP
connector to minimize the possibility of damage. If the
PUSH-OP connector is to be stored for any length of time
prior to installation, provide a clean, dry storage area.
Standards
ISO 9001 Certified Quality Management System
Figure 1. 600 A PUSH-OP Connector
Figure 2. One-line diagram of a three-phase cable connected to a three-phase switch on either end.
S1
S2
WARNING
600 A PUSH-OP connectors are designed to be operated
in accordance with normal safe operating procedures.
These instructions are not intended to supersede or
replace existing safety and operating procedures.
Connectors must be de-energized during operation or
maintenance. Visible break and adequate grounding
must be provided before cable work proceeds. (Ensure
that the component is rated for the intended application
before it is installed.)
PUSH-OP connectors should be installed and serviced
only by personnel familiar with good safety practice
and the handling of high-voltage electrical equipment.
Failure to comply may result in death, severe personal
injury or equipment damage.
1600 A PUSH-oP DeADbreAk connector oPerAtion inStrUctionS MN650011EN May 2017
