11EATON Series 1 Heavy Duty Hydrostatic Fixed Displacement Motors Parts and Repair E-MOPI-TS002-E September 2004
Parts
Valve Block Kits
Table 4.6 Valve Block Sealing Kit
Kit No. 990029-001
ITEM PART
NO. NO. QTY. DESCRIPTION
1 101129-000 2 Back-up Ring
2 8765-118 2 O-ring
3 8775-018 1 Seal Ring
4 8775-021 1 Seal Ring
Table 4.5 Shuttle Valve Service Kit
For Valve Block S/A (High Rate Shuttle Spring)
Kit No. 990071-000
ITEM PART
NO. NO. QTY. DESCRIPTION
1 8785-010 2 Tube Fitting, O-ring
2 101729-000 2 Valve Plug
3 102418-000 1 Shuttle Spool
4 101730-000 2 Shuttle Valve Spring
5 101727-000 2 Shuttle Valve
Table 4.7 High Pressure Relief Valve Seal Kit
Kit No. 990104-000
ITEM PART
NO. NO. QTY. DESCRIPTION
1 8785-014 1 Tube Fitting, O-ring
2 8770-0117 2 Back-up ring
3 8765-117 1 O-ring
Table 4.4 Low Rate Shuttle Valve Service Kit
Kit No. 990202-000
ITEM PART
NO. NO. QTY. DESCRIPTION
1 8785-010 2 Tube Fitting, O-ring
2 101729-000 2 Valve plug
3 102530-000 2 Shuttle Valve Spring
4 102418-000 1 Shuttle Spool
5 101727-000 2 Shuttle Valve
Table 4.8 High Pressure Relief w/Thd. Retainer
Seal Kit
Kit No. 990554-000
ITEM PART
NO. NO. QTY. DESCRIPTION
1 8785-008 1 Tube Fitting, O-ring
2 8785-014 1 Tube Fitting, O-ring
3 8770-020 2 Back-up ring
4 8765-020 1 O-ring
Table 4.3 Valve Block Subassembly
VALVE
BLOCK *HPRV *HPRV SHUTTLE
S/A BLOCK A-PORT B-PORT LPRV SPRING DESCRIPTION
101732-XXX 107131-000 101047-XXX 101047-XXX 101048-016 101730-000 160 psi, LPRV, High Rate
102687-XXX 107131-000 101047-XXX 101047-XXX 101048-022 101730-000 220 psi, LPRV, High Rate
102769-XXX 107131-000 101047-XXX 101047-XXX 101048-020 101730-000 200 psi, LPRV, High Rate
103062-XXX 107131-000 101047-XXX 101047-XXX 103355-016 101730-000 160 psi, Orifice LPRV, Low Rate
103071-XXX 107131-000 101047-XXX 101047-XXX 101048-028 101730-000 280 psi, LPRV, High Rate
103533-XXX 107131-000 103114-XXX 103114-XXX 101048-028 101730-000 280 psi, LPRV, High Rate, HPRV w/THD. Retainer
104923-XXX 107131-000 103114-XXX 103114-XXX 103355-016 101730-000 160 psi, Orifice LPRV, Low Rate, HPRV w/THD. Retainer
104955-XXX 107131-000 103114-XXX 103114-XXX 101048-016 101730-000 160 psi, LPRV, High Rate, HPRV w/THD. Retainer
105941-XXX 107131-000 101047-XXX 101047-XXX 101048-028 102530-000 280 psi, LPRV, High Rate
105963-XXX 107131-000 103114-XXX 103114-XXX 103355-022 102530-000 220 psi, Orifice, LPRV, Low Rate HPRV w/THD. Retainer
105964-XXX 107131-000 103114-XXX 103114-XXX 101048-028 102530-000 280 psi, LPRV, High Rate, HPRV w/THD. Retainer
106707-XXX 101731-000 101047-XXX 101047-XXX 101048-018 101730-000 180 psi, LPRV, High Rate
107134-000 – – – – – End Cover Sealing Plate
107149-XXX 107131-000 103114-XXX 103114-XXX 103355-016 102530-000 160 psi, Orifice LPRV, Low Rate, HPRV w/THD. Retainer
107196-XXX 107131-000 101047-XXX 101047-XXX 103072-030 101730-000 300 psi, LPRV, High Rate
110618-XXX 107131-000 101047-XXX 101047-XXX 101048-024 101730-000 240 psi, LPRV, High Rate
*Note: High pressure relief setting XXX=lbf/in
2
Table 4.9 End Cover Sealing Plate Kit
Kit No. 990003-001
ITEM PART
NO. NO. QTY. DESCRIPTION
1 107134-000 1 End cover Sealing Plate
2 095863-150 4 Hex head Bolts
3 008765-118 2 O-Ring
4 101129-000 2 Backup Ring
5 008775-021 1 Sealing Ring
