P-164000427 SMALL and LARGE BATTERY CABINET 6
Revision 2 User's and Installation Guide
2
Installation
The
battery system provides emergency short-term
backup
power
to
safeguard operation during
brownouts, blackouts,
and other
power interruptions.
By
default, 93PM and 93E UPSs are
configured
to use valve-regulated lead-acid (VRLA)
batteries. For the battery specification, see
UPS User’s and Installation Guide.
Should
there
be a need to
connect
other type of
batteries
or
other
energy storage means, a
certified
service technician
should be
consulted
prior to
proceeding
with
installation.
For the 93PM and 93E product lines, there are two different battery cabinets: Small and Large
Battery Cabinet. The battery block configuration in the chosen battery cabinet must always match
the UPS requirement. Used battery configuration must be inserted into UPS settings during
commissioning or start-up. Refer to UPS installation and operation manual for UPS configuration.
The allowed battery block configurations for 93PM and 93E UPSs are presented in table 2-1.
Table 2-1. Battery block configuration for 93PM and 93E UPSs.
DANGER
Battery
strings
with
different battery quantity
and
voltage
may not be
connected
in
parallel.
Make sure that 93PM 30-50kW UPS with internal batteries always uses 36 battery blocks per string.
External battery strings must also contain 36 battery blocks per string.
Battery cabinet internal power wiring, Battery-to-UPS power wiring
and control wiring for
integral line-up and
match battery cabinets
are
supplied
with the Small Battery
C
abinet. Large
Battery Cabinet is provided only with battery cabinet internal power wiring and control wiring.
There are
several
cable
entries
in the
battery cabinets. The cabinets can be
wired in the following
ways:
through
the left side
panel
t
hrough
the right side
panel
through
the back
wall
through
the
roof
through
the
bottom
(only Large Battery Cabinet)
