Eaton 93PM Emergency Lighting UPS (50 kW, 480V Three and Four-Wire UL 924) Installation and Operation Manual P-164000569—Rev 03 73
Table 16. Display Menu Operation
Function Subfunction
Operation
Home
An overview of UPS operation, including information on load, efficiency and
consumption.
Meters – UPS The meter screens show the UPS meter readings for the unit. The default voltage
displayed on these screens is phase-to-neutral. These can be changed to display
the voltage phase-to-phase (A-B, B-C, C-A). Tap the METERS tab on the main
menu navigation bar to display the METER SUMMARY screen (see Figure 48).
The current UPS readings are displayed in the information area of the screen. To
display individual meter details, tap the desired meter button to display the
detailed meter screen.
Output – UPS The Output screen shows output voltage (phase to neutral), output current (each
phase), and frequency being supplied by the UPS, as well as the kVA, kW, and
power factor measurements.
Input – UPS The Input screen shows input voltage (phase to neutral), input current (each
phase), and frequency of the incoming utility source, as well as the kVA, kW, and
power factor measurements.
Bypass
The Bypass screen shows the bypass input voltage (phase to neutral), input
current (each phase), and frequency of the incoming utility source, as well as the
kVA, kW, and power factor measurements.
Battery – UPS The Battery screen displays the battery voltage (Vdc) and the battery current
(Idc).
Mimics UPS Mimic Tap the MIMICS tab on the main menu navigation bar to display an overview of
UPS operation, including information on load, efficiency and consumption. If
there is an error, an error indicator is displayed next to the affected part. Active
events log can be opened by tapping the error indicator.
UPS Module Map Tap the UPS MODULE MAP tab on the secondary menu navigation bar to
display the status of each UPM.
System Overview Tap the SYSTEM OVERVIEW tab on the secondary menu navigation bar to
display the status and meters summary for each UPS.
ESS Tap the ESS tab on the secondary menu navigation bar to display the
approximate consumption and energy savings of ESS mode.
Logs Active Tap the LOGS tab on the main menu navigation bar to display the ACTIVE
EVENTS screen (see Figure 49). A listing of all system events that are currently
active is displayed. The most recent event is listed first. As events clear, they are
removed from the Events listing. To scroll through the events, press the up or
down scroll bar.
System Log (Historical) Tap the SYSTEM LOG tab on the secondary menu navigation bar to display the
SYSTEM LOG screen (see Figure 50). The history Log lists up to 512 events in
chronological order, with the most recent event listed last (once 512 is reached,
the earliest event is overwritten). The end of the log (the most recent events) is
displayed first; scroll upward to view older event listings. To scroll through the
events, press the up or down scroll bar.
Settings Configurable system settings. Tap the SETTINGS tab on the main menu
navigation bar to display the settings screen. Settings may be password
restricted. Settings Level 2 default password is 0101.
UPS Operating Instructions
