6.3 Display functions
Press the Enter ( ) button to activate the menu options. Use the two middle buttons ( and ) to scroll
through the menu structure. Press the Enter ( ) button to select an option. Press the button to cancel
or return to the previous menu.
Main menu Submenu Display information or Menu function
Measurements [Total Load] W VA A PF / [Load phase 1 (N-L1)] W VA A PF /
[Load] phase 2 (N-L2)] W VA A PF] / [Input/Bypass] V-L1 V-L2 Hz /
[TotalOutput(L1-L2)]VHz/[Efficiency]%/
[Battery] % min V n° / [DC bus] V / [Average power usage]
Wh /
Control Go to Bypass /
Go back normal
Transfers the UPS on Bypass mode /
Transfers the UPS on Line mode
Start battery test Starts a manual battery test
Reset fault state Clears active fault
Restore factory set Returns all settings to original values
Reset average power Clears average power usage measurement
Reset cumul. power Clears cumulated power usage measurement
Dry contacts test Tests dry contact relay outputs
Settings Local settings Sets product general parameters
In/Out settings Sets Output parameters
On/Off settings Sets On/Off conditions
Battery settings Sets battery configuration
Event log Event filter Selects faults, alarms and/or events to display
Event list Displays the events stored
Reset event list Clears events
Fault log Fault list Displays the faults stored
Reset fault list Clears faults
Identification [Product type/model] / [Part/Serial number] / [UPS/NMC
firmware] / [Com card IPv4], [Com card IPv6], [Com card MAC] /
[Detected accessories]
Register product Links to Eaton registration website
6.4 User settings
The following table displays the options that can be changed by the user.
Submenu Available settings Default settings
Local settings
Language [English] [Français] [Español]
[Português]
Menus, status, notices and alarms,
UPS fault, Event Log data and
settings are in all supported
languages.
[English]
User selectable when UPS is
powered for the first time.
Date/ time Format:
[International] [US]
[US]
LCD Modify LCD screen brightness and
contrast to be adapted to room light
conditions.
Audible alarm [Enabled] [Disabled on battery] [Always
disabled]
Enable or disable the buzzer
if an alarm occurs.
[Enabled]
In/Out settings
Output voltage [100V] [110V] [115V] [120V] [127V]
Can be changed only in Standby mode
[120V]
Output frequency Frequency converter:
[Enabled] [Disabled]
Frequency settable in frequency
converter mode
Disabled
Output mode [Industrial] [Network]
Set UPS behavior regarding transfer
on Bypass
[Network]
Input volt hysteresis Sets input voltage hysteresis
from 1 to 10V
[10V]
High Efficiency
mode
[Enabled] [Disabled]
Power the output from Bypass
for high efficiency
[Disabled]
6. HMI and settings
