14
Programming
DPCT IOM INSTRUCTION OPERATION MANUAL MN124018EN January 2023 www.eaton.com
Proof Pressure Switch Enabled / Disabled
Pressure Units PSI / BAR / kPa
Pressure Transducer Enabled / Disabled
Calibrate Pressure Transducer
Calibrate Using 0 PSI / Calibrate Using
Current Pressure / Reset to Factory Default
Timer values
Minimum Run Time
Four (4) digit numeric entry in Minutes:
Seconds / Disabled
Sequential Start Timer 0-999 seconds / Disabled
AC Power Failure Alarm 0-999 minutes
AC Power Failure Start Enable/Disable
Weekly Motor Test Timer Enabled / Disabled
Day of the Week Any valid day of the week
Time of Day 24 Hours
Test Interval 1-52 weeks
Run Time
Four (4) digit numeric entry in Minutes:
Seconds / Disabled
Drain Valve Solenoid Enabled / Disabled
Alarm setpoints
Source Voltage Alarm Setpoint
Under Voltage 0-100%/Disabled
Over Voltage 0-100%/Disabled
Battery Voltage Alarm Setpoint
Under Voltage 0-28Vdc/Disabled
Over Voltage 14-50Vdc/Disabled
Transducer Fail Engine Start Enabled / Disabled
Abort Engine Test Enabled / Disabled
Inputs/outputs
Input 1 See Table 3
Input 2 See Table 3
Input 3 See Table 3
Input 4 See Table 3
Input 5 See Table 3
Input 6 See Table 3
Input 7 See Table 3
Input 8 See Table 3
Input 9 See Table 3
Input 10 See Table 3
Input On Delay Timer 0-999 seconds / Disabled
Input Off Delay Timer 0-999 seconds / Disabled
Latch Until Reset Enabled / Disabled
Failsafe Enabled / Disabled
1CR Relay See Table 4
2CR Relay See Table 4
3CR Relay See Table 4
4CR Relay See Table 4
Pressure Above 0-999 PSI / Disabled
Pressure Below 0-999 PSI / Disabled
Load Shed Controller Start
Delay
0-10 seconds / Disabled
Relay On Delay Timer 0-999 seconds / Disabled
Relay Off Delay Timer 0-999 seconds / Disabled
Latch Until Reset Enabled / Disabled
Failsafe Enabled / Disabled
5.3 Startup tab
Refer to Appendix B for the menu structure of the
Startup tab.
5.3.1 Quick setup
Quick Setup is a step-by-step process that allows the user
to program the time, day of the week, date, source voltage,
battery voltage, start pressure, stop pressure, automatic
shutdown, and minimum run time (if automatic shutdown
was enabled). If all settings are correct, the user will press
Accept to save the changes.
5.3.2 Manual/automatic start
Records the number of times and the duration of each run,
both via Automatic and Manual means into the Startup file.
Manual Starts provides a Crank #1, Crank #2, and Stop
button on-screen to initiate manual calls to start. The screen
will show the source voltage, battery voltage, charging
current, pressure and Crank #1 and Crank #2 start counters.
Automatic Starts provides a “Drop Pressure” button that will
energize the drain valve solenoid to drop pressure within the
sensing line. When the controller registers a low-pressure
condition, the drain valve will close, and the controller will
initiate an automatic crank cycle. If activating the drain valve
solenoid is not ideal, the user can manually drop pressure
from the sensing line to achieve the same outcome.
5.3.3 Test alarm
Buttons are used to trigger specific output relays to verify
alarm connections and general operation of the relay. The
relay will stay latched until either the button is depressed
again or until the user leaves the screen.
5.3.4 USB download
Allows the user to save the statistics, diagnostics, message
history, start up, and configuration files to a USB device.
