2 KA369R, KA542R, AND KA57WE AUXILIARY SWITCH KIT INSTALLATION AND ADJUSTMENT INSTRUCTIONS MN280031EN
Table 1. Auxiliary Switch Kit Contents
Item Part Number Description Quantity
1* KA235R11 Switch, single stage (KA369R) 1
KA235R22 Switch, two stage (KA369R)
KA235R33 Switch, three stage (KA369R)
KA1102R11 Switch, single stage (KA542R)
KA1102R22 Switch, two stage (KA542R)
KA1102R33 Switch, three stage (KA542R)
KP153WE11 Switch, single stage (KA57WE)
KP153WE22 Switch, two stage (KA57WE)
KP153WE33 Switch, three stage (KA57WE)
2 KP2000A3 Rubber o-ring shaft seal 1
3 KA351R Switch operating shaft and lever 1
4 KP86 Type E retaining ring
5 KP613 Sstl machine scrs - 1/4”-20 x 5/8”, switch mtg. 4
6 KP563 Sstl lock washers - 1/4” 4
7 KP2013A44 Type E retaining ring 1
8 KP335 Brass washers No. 10S 7/16” O.D. x 3/16” I.D. 2
9 KP651R Switch link 1
10 KP84 C retaining ring 1
11 KP655R Nameplate - contact designation 1
12 KP69 Sstl self-tapping scr - No. 2 x 3/16” 2
13 KP608R Switch housing cover 1
14 KP649R Cover gasket 1
Mounting Plate 1
* Item 1 will vary depending on kit selection.
