Eaton HMi VU Series User Manual

HMi VU Series Instruction Leaflet
Specifications
MODEL HMIVU06CUNBE HMIVU07CUNBE HMIVU08CUNBE HMIVU10WCUNBE
5.6” TFT LCD 7” TFT LCD 8” TFT LCD
10.1” Widescreen
TFT LCD
Display Type
(65536 colors)
Resolution 320 x 234 pixels 800 x 600 pixels 1024 x 600 pixels
Backlight
LED Back Light
(20,000 hours
half-life at 25
o
C)
(Note 1)
LED Back Light (10,000 hours half-life at 25
o
C)
(Note 1)
Brightness
NIT Rating
200 dc/m
2
200 dc/m
2
250 dc/m
2
200 dc/m
2
LCD MODULE
Display Size
113.28 x
84.70mm
141 x 105.75mm 162 x 121.5mm 226 x 128.7mm
Operation System Real Time OS
MCU 32-bit RISC Micro-controller
NOR Flash ROM
Flash ROM
8 MB
(OS System:
2MB/User
Application: 6MB)
Flash ROM 128 MB(OS System: 30MB / Backup: 16MB / User
Application: 82MB)
SDRAM 16Mbytes 64Mbytes
Backup Memory 128Kbytes 16Mbytes
Buzzer Multi-Tone Frequency (2K ~ 4K Hz) / 85dB
Sound
Effect
Output
AUX N/A Stereo output
Ethernet Interface N/A
IEEE 802.3, IEEE 802.3u
10/100 Mbps
auto-sensing
has built-in isolated power circuit
(Note 3)
Memory Card N/A SD Card (supports SDHC)
USB
1 USB Host
(Note 2)
Ver 1.1 / 1 USB
Client Ver 1.1
1 USB Host
(Note 2)
Ver 2.0 / 1 USB Client Ver 1.1
COM1 RS-232 (supports hardware flow control)
COM2 RS-232 / RS-485
RS-232 / RS-422 / RS-485
has built-in isolated power circuit
(Note 3)
Serial
COM Port
COM3 RS-422 / RS-485
RS-232 / RS-422 / RS-485
has built-in isolated power circuit
(Note 3)
EATON CORPORATION www.eaton.com 17
