Eaton Powerware Series Installation Instructions

Eaton 9395 UPS (650–825 kVA) Single Feed Kit S 164201773 Rev 2 www.eaton.com/powerquality
1
Eaton 9395 UPS (650–825 kVA) Single-Feed Kit Installation
NOTE Refer to the applicable installation and operation manual supplied with the UPS during installation.
W A R N I N G
Installation should be performed only by qualified personnel.
To install the single-feed kit:
1. If not already accomplished, remove one top screw and two bottom screws
securing each ISBM section left and right front panel (refer to the applicable
Eaton 9395 UPS manual for panel location). Lift the panels straight up to remove
them from the panel hanger brackets at the top of the cabinet.
2. If not already accomplished,remove the screws securing the top and bottom
internal safety shield panels and remove the panels to gain access to the rectifier
and bypass input terminals. Retain the hardware for later use.
3. Using M12 hardware from the UPS external wiring terminal hardware kit, install
the single-feed bus bar extensions (see Table 1) onto the back side of the
rectifier input bus bars (see Figure 1). Mount the extension bar using the two rear
holes on the bus bar. Tighten the bolts to the torque values in Table 2.
4. Using M12 hardware from the UPS external wiring terminal hardware kit, install
the single-feed jumper cables from the kit (see Table 1) between the rectifier
input bus bar extension and the bypass input terminal (see Figure 1). Verify each
rectifier phase terminal is jumpered to the same phase on the bypass terminal.
Use the two bottom rear holes on the bus bar extensions and bypass input bus
bars. Tighten the bolts to the torque values listed in Table 2.
Table 1. Supplied Terminal Hardware
Part Size Quantity Terminals Used On Eaton Part Number
Jumper Cable N/A 12 (4 per phase) Rectifier and Bypass Input 152602718 (wire kit with 12 cables)
Bus Bar Extension N/A 3 Rectifier Input 119201546
Bolt, Grade 5 M12 50 mm 18 Rectifier and Bypass Input 180190078-115
Tie Wrap 0.30” W 14.5” L 6 Jumper Cables 152201082
Table 2. Single-Feed Power Cable Terminations
Terminal Function Terminal Function Bus Landing Tightening Torque Nm (lb ft) Bolt Size
Bus Bar Extension
E1 Phase A 2 – 1 bolt mounting
76 (56)
M12
E2 Phase B 2 – 1 bolt mounting
76 (56)
M12
E3 Phase C 2 – 1 bolt mounting
76 (56)
M12
Rectifier Input
E1 Phase A 2 – 1 bolt mounting
76 (56)
M12
E2 Phase B 2 – 1 bolt mounting
76 (56)
M12
E3 Phase C 2 – 1 bolt mounting
76 (56)
M12
Bypass Input
E6 Phase A 2 – 1 bolt mounting
76 (56)
M12
E7 Phase B 2 – 1 bolt mounting
76 (56)
M12
E8 Phase C 2 – 1 bolt mounting
76 (56)
M12
