TRSM0940 Service Procedures | Output Shaft Speed Sensor Removal and Installation
Output Shaft Speed Sensor Removal and Installation
Special Instructions
The Directional Output Shaft Speed Sensor is used on the
Fuller® Advantage model Transmissions. The Output Shaft
Speed Sensor location may vary depending on OEM design
specifications. The sensor will be located at 10 o’clock on
the Output Shaft Housing in heavy-duty models
Special Tools
Basic hand tools
Component Identification
1. Cap Screw
2. 2-Way Directional Output Shaft Speed Sensor
1
2
