Eaton UPS 20 User Manual

53UPS 20-40 kVA, 230/400 V 50/60 Hz output
User’s Guide
1025358
Revision D
13. Technical data
Standards
UPS 20 kVA 30 kVA 40 kVA
Safety IEC 62040-1-1, EN 62040-1-1 and EN 60950
EMC EN 50091-2
Product IEC 62040-3 and EN 62040-3
Environment
UPS 20 kVA 30 kVA 40 kVA
Amb. temperature 0 to +40°C (electronics), 15 to +25°C (batteries)
Relative humidity 0 to 95%, no condensation allowed
Altitude <1000 m above sea level
Vibration IEC 68-2-6; max. 0.3 mm (2 to 9 Hz), max. 1 m/s2 (9 to 200 Hz) sinusoidal
Maintenance configuration
UPS 20 kVA 30 kVA 40 kVA
Dimensions
- Width
- Depth
- Height
494 mm
762 mm
1684 mm
Weight
- no battery
- 36 battery
- 72 battery
- 108 battery
- 144 battery
200 kg
300 kg
400 kg
500 kg
600 kg
217 kg
317 kg
417 kg
517 kg
617 kg
Colour RAL 9005 black
Characteristics
Powerware 9355 20 kVA 30 kVA 40 kVA
Efficiency
- nominal load Up to 93% Up to 93% Up to 93%
Heat losses <1600 W <1900 W <2550 W
Backup time
- load pf 0.7
- temperature 25°C
5 min (36 bat 9Ah)
13 min (72 bat 9Ah)
22 min (108 bat 9Ah)
31 min (144 bat 9Ah)
-
7 min (72 bat 9Ah)
13 min (108 bat 9Ah)
20 min (144 bat 9Ah)
-
-
8 min (108 bat 9 Ah)
12 min (144 bat 9 Ah)
Noise (ISO 7779)
50 - 53 dB(A) depending on
the load
50 - 53 dB(A) depending on
the load
50 - 53 dB(A) depending on
the load
