22
CS-520
MAINTENANCE AND CARE
IMPORTANT
Time intervals shown are maximum.
Actual use and your experience will determine
the frequency of required maintenance.
Your ECHO chain saw is designed to provide many
hours of trouble free service. Regular scheduled
maintenance will help your chain saw achieve that
goal. If you are unsure or are not equipped with the
necessary tools, you may want to take your unit to
an ECHO Service Dealer for maintenance. To help
you decide whether you want to DO-IT-YOURSELF
or have the ECHO Dealer do it, each maintenance
task has been graded. If the task is not listed ask
your ECHO dealer for repairs.
SKILL LEVELS
Level 1 = Easy to do. Most required tools come
with unit.
Level 2 = Moderate difficulty. Some specialized
tools may be required.
Level 3 = Experience required. Specialized tools
are required. ECHO recommends that
the unit be returned to your ECHO dealer
for servicing.
ECHO offers REPOWER™ Maintenance Kits and
Parts to make your maintenance job easier. Just
below each task heading are listed the various part
numbers required for that task. Ask your ECHO
dealer for these parts.
MAINTENANCE INTERVALS
Meintenance Procedure Letter Codes:
I = INSPECT
C = CLEAN
R = REPLACE
*=All recommendations to replace are based
on the finding of damage or wear during
inspection.
Component/system Maintenance procedure
Recommended ECHO Dealer Maintenance Procedures
Cylinder Exhaust Port Inspect/Clean/Decarbon 3 I/C
Do-It-Yourself Maintenance Procedures
Air Filter Inspect/Clean/Replace 1 I/C R*
Automatic Oiler Inspect/Adjust 1I
Oil Filter Inspect/Replace 1 I/R*
Fuel Filter Inspect/Replace 1IR*
Guide Bar and Oil Holes Inspect/Clean 1 I/C
Sprocket Inspect/Replace 2 I/R*
Spark Plug Inspect/Clean/Replace 2 I/C R*
Cooling System Inspect/Clean 2 I/C
Muffler Spark Arrestor Inspect/Clean/Replace 2I/R*
Starter Rope Inspect/Replace 1 I/R*
Screws/Nuts/Bolts Inspect/Tighten/Replace 1 I/R*
Every refuel Required Skill level Daily or Before use 3 Months or 90 Hours 6 Months or 270 Hours Yearly or 600 Hours

Echo cs-520 Specifications

General

Engine Displacement	50.2 cc
Engine Type	2-stroke
Bar Length	16, 18, 20 inch
Chain Pitch	0.325 inches
Fuel Capacity	0.59 liters
Power Output	2.7 kW
Fuel Tank Capacity	0.59 liters
Chain Gauge	0.050 inches
