Echo PB-265L User Manual

8
1. SAFETY DECAL - Lists important safety precautions.
2. SAFETY DECAL - Lists important safety precautions.
3. SAFETY DECAL - Lists important safety precautions.
4. SPARK PLUG - Provides spark to ignite fuel mixture.
5. SPARK ARRESTOR MUFFLER OR SPARK ARRESTOR MUFFLER WITH CATALYST -The mufer or
catalytic mufer controls exhaust noise and emission. The spark arrestor screen prevents hot, glowing particles of
carbon from leaving the mufer. Keep exhaust area clear of ammable debris.
6. SERIAL NUMBER LABEL - Lists model number and serial number of unit.
7. RECOIL STARTER HANDLE - Pull recoil handle slowly until starter engages, then quickly and rmly. When
engine starts, return handle slowly. DO NOT let handle snap back or damage to unit will occur.
8. FUEL TANK CAP - Covers and seals fuel tank.
9. FUEL TANK - Contains fuel and fuel lter.
10. AIR CLEANER - Contains replaceable air lter element.
11 . HANDLE - Rotates downward for throttle control access. Spring loaded for exible operation.
12. THROTTLE POSITION LEVER/STOP SWITCH - Combination stop switch and variable speed throttle lever.
When the lever is moved all the way forward the blower is at Wide Open Throttle (W.O.T.). When the lever is
moved rearward to detent, the blower is at idle. When the lever is moved rearward past the idle detent the blower
will stop.
13. CHOKE - Choke is located on the side of the air cleaner. Move choke lever to "COLD START" ( ) to close
choke for cold starting. Move choke lever to "RUN" ( ) position to open choke.
14. PURGE BULB - Pumping purge bulb before starting engine draws fresh fuel from the fuel tank, purging air from
the carburetor. Pump purge bulb until fuel is visible and ows freely in the clear fuel tank return line. Pump purge
bulb an additional 4 or 5 times.
15. SHOULDER HARNESS - Used to support unit on operator's back. The straps are adjustable.
16. BLOWER PIPES - Exclusive positive locking system.
17. FLEXIBLE PIPE - Allows for full range of movement.
18. STICK HANDLE - Used by operator to direct air ow.

Echo PB-265L Specifications

General

Engine Displacement	25.4 cc
Air Speed	170 mph
Type	Handheld
Power Source	Gasoline
Engine Type	2-Stroke
Fuel Capacity	16.9 fl oz
Noise Level	70 dB
