ECS A740GM-M User Manual

34
Using BIOS
Integrated Peripherals
This page sets up some parameters for peripheral devices connected to the system.
CMOS Setup Utility - Copyright (C) 1985-2007, American Megatrends, Inc.
Integrated Peripherals
Onboard IDE Controller Enabled
SATA Configuration Enanled
Onboard SATA Mode IDE
Onboard AUDIO Function Enabled
Onboard LAN Function Enabled
Onboard LAN Boot ROM Disabled
Serial Port1 Address 3F8&IRQ4
OnBoard IR Disabled
Parallel Port Address 378
Parallel Port Mode ECP
ECP Mode DMA Channel DMA3
Parallel Port IRQ IRQ7
USB Functions Enabled
Legacy USB Support Enabled
Help Item
Serial Port1 Address (3F8/IRQ4)
Use this item to enable or disable the onboard COM1 serial port, and to assign a port
address.
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
Options
Disabled
Enabled
OnBoard IDE Controller (Enabled)
SATA Configuration (Enabled)
Use this item to show the Serial ATA Configuration options: Disabled, Compatible,
Enhanced.
OnBoard SATA Mode (IDE)
OnBoard AUDIO Function (Enabled)
Use this item to enable or disable the onboard Audio function.
OnBoard LAN Function (Enabled)
Use this item to enable or disable the onboard LAN function.
OnBoard LAN Boot ROM (Disabled)
Use this item to enable or disable the booting from the onboard LAN or a network
add-in card with a remote boot ROM installed.
OnBoard IR (Disabled)
Use this item to enable or disable the onboard IDE interface.
Use this item to enable or disable the onboard SATA mode.
This item is used to enable or disable the onboard infrared port, and to assign a port
address.
Parallel Port Address (378)
Use this item to enable or disable the onboard Parallel port, and to assign a port
address.
