5
B350AM4-M USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket Socket AM4
2. CPU_FAN 4-pin CPU cooling fan connector
3. DIMM_1~4 288-pin DDR4 Module slots
4. ATX_POWER Standard 24-pin ATX power connector
5. BT Battery
6. NGFF1~2 M.2 slots
7. SATA1~4 Serial ATA 6.0 Gb/s connectors
8. CLR_CMOS Clear CMOS jumper
9. USB3F Front Panel USB 3.0 header
10. F_USB2 5-pin Front Panel USB 2.0 headers
11. F_USB1 10-pin Front Panel USB 2.0 headers
12. SYS_FAN1~2 4-pin System cooling fan connectors
13. F_PANEL Front panel switch/LED header
14. LPT Printer header
15. COM1~2 Onboard serial port headers
16. CASE Case open header
17. F_AUDIO Front panel audio header
18. PCIEX16_1~2 PCI Express slots for graphics interface
19. BZ Buzzer
20. PCI 32-bit add-on card slot
21. PCIEX1 PCI Express x1 slot
22. ATX_12V 4-pin +12V power connector
