ECS B350AM4-M User Manual

Chapter 3
B350AM4-M USER MANUAL
61
Main Advanced Chipset M.I.B. X Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
This page enables you to set the keyboard NumLock state.
Boot Menu
Operation System Select (Windows 8.x / 10)
This item is used to select the operation system.
Launch PXE OpROM (Disabled)
The item enables or disables launch PXE Option ROM.
Launch Storage OpROM (Enabled)
Use this item to enable or disable the Storage OpROM.
Fast Boot (Enabled)
This item enables or disables boot with initialization of a minimal set of device
required to launch active boot option. Has no effect for BBS boot options.
VGA Support (EFI Driver)
If auto, only install legacy OpROM with legacy OS and Post logo will not be shown
during post. EFI driver still be installed with EFI OS.
USB Support (Full Initial)
If you select Disabled, all USB devices will not be available until after OS boot. If you
select Partial Initial, specific USB port/device will not be available before OS boot.
If you select Full Initial, all USB devices will be available in OS and POST.
Network Stack Driver Support (Disabled)
If disabled, Network stack driver will be skipped.
Bootup NumLock State (On)
This item enables you to select NumLock state.
Quiet Boot (Enabled)
This item enables or disables quiet boot.
Windows 7 or other OS:
Boot policy for Legacy OS.
Windows 8.x / 10: Boot
policy for UEFI OS without
Compatibility Support
Module(CSM).
Manual: User customized
CSM parameters & boot
policy.
Boot Configuration
Operation system Select Windows 8.x / 10
Launch PXE OpROM Disabled
Launch Strorage OpROM Enabled
Fast Boot Enabled
VGA Support EFI Driver
USB Support Full Initial
Network Stack Driver Support Disabled
Bootup NumLock State On
Quiet Boot Enabled
Boot mode select UEFI
Set Boot Priority
Boot Option #1 Hard Disk: Windows Bo...
Boot Option #2 CD/DVD
Boot Option #3 USB Hard Disk
Boot Option #4 USB CD/DVD
Boot Option #5 USB Flash: UEFI: USB,...
Boot Option #6 USB Floppy
Boot Option #7 Network
UEFI Hard Disk Drive Priorities
UEFI USB Flash Drive Priorities
