ECS C51GM-M User Manual

44
Using BIOS
PC Health Status
On motherboards that support hardware monitoring, this item lets you monitor the param-
eters for critical voltages, critical temperatures, and fan speeds.
Menu Level
Item Help

Phoenix - Award WorkstationBIOS CMOS Setup Utility
PC Health Status
Smart Fan Function [Press Enter]
Shutdown Temperature [Disabled]]
Warning Temperature [Disabled]
CPU Tcontrol 62
o
C
System Temperature 34
o
C
CPU Fan Speed 0 RPM
System Fan Speed 2755 RPM
CPU Vcore 1.39V
VDIMM 1.77V

Smart Fan Control (Disabled)
This item allows you to enable/disable the control of the system fan speed by changing by
changing the fan voltage.
Phoenix-Award WorkstationBIOS CMOS Setup Utility
Smart Fan Function
 Smart Fan Function (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
X
Item Help

Menu Level
Smart Fan Control [Disabled]
FAN1 START PWM VALUE 0
FAN1 START Temp
o
C 0
FAN1 Limit Temp
o
C 0
FAN1 Slope Select PWM/
o
C 0
X
X
X

F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults F10:Save
: Move Enter: Select +/-/PU/PD:Value ESC:Exit F1: General Help F2: Item Help

F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults F10:Save
: Move Enter: Select +/-/PU/PD:Value ESC:Exit F1: General Help F2: Item Help
