Using BIOS
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
CPU Fan Speed : 4115 RPM
CPU Voltage : 1.236V
IMC Voltage : 1.068V
DIMM Voltage : 1.548V
VAXG Voltage 1.032V
-=- PECI Mode -=-
Offset to TCC Activation Temp. : -24
Smart Fan Function
f
PC Health Status
CPU Smart Fan Control [Enabled]
SMART Fan Mode [Normal]
SMART Fan start PWM value 180
SMART Fan start PWM TEMP(-) 30
Delta T +3
SMART Fan Slope PWM value 10 PWM value/unit
CPU Fan Full Speed Offset (-) 23
Scroll to this item and press <Enter> to view the following screen:
fSmart Fan Function
CPU Smart Fan Control (Enabled)
This item allows you to enable/disable the control of the CPU fan speed by changing
the fan voltage.
SMART Fan Mode (Normal)
This item allows you to select the fan mode (Normal, Quiet, Silent or Manual) for a
better operation environment. If you choose Normal mode, the fan speed will be auto
adjusted depending on the CPU temperature. If you choose Quiet mode, the fan speed
will be auto minimized for quiet environment. If you choose Silent mode, the fan
speed will be auto restricted to make system more quietly. If you choose Manual
mode, the fan speed will be adjust depending on users’ parameters.
