Using BIOS
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
paeameters for critical voltages, temperatures and fan speeds.
Main Advanced Chipset M.I.B III Boot Security Save & Exit
System Temperature : 33°C
CPU Fan Speed : 2974 RPM
System Fan Speed : 0 RPM
CPU Voltage : 1.236V
IMC Voltage : 1.056V
DIMM Voltage : 0.456V
PCH Voltage : 1.056V
PC Health Status
Smart Fan Function
¢
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
-=- PECI Mode -=-
Offset to TCC Activation Temp : -49
CPU SMART FAN Control (Enabled)
This item allows you to enable/disable the control of the CPU fan speed by changing
the fan voltage.
SMART Fan Mode (Normal)
This item allows you to select the fan mode (Normal, Quiet, Silent, or Manual) for a
better operation environment. If you choose Normal mode, the fan speed will be auto
adjusted depending on the CPU temperature. If you choose Quite mode, the fan speed
will be auto minimized for quiet environment. If you choose Silent mode, the fan
speed will be auto restricted to make system more quietly. If you choose Manual
mode, the fan speed will be adjust depending on users’ parameters.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
CPU SMART Fan Control [Enabled]
SMART Fan Mode [Normal]
SMART Fan start PWM value 180
SMART Fan start PWM TEMP(-) 30
Delta T +3
SMART Fan Slope PWM value 10 PWM value/unite
CPU Fan Full Speed Offset (-) 23
Scroll to this item and press <Enter> to view the following screen:
¢Smart Fan Function
Main Advanced Chipset M.I.B III Boot Security Save & Exit
+/- : Change Opt.
Enter : Select
F1: General Help
“¤
«‹
:Select Screen
:Select Item
F2: Previous Values
F3: Optimized Defaults
ESC: Exit
F4: Save & Exit
+/- : Change Opt.
Enter : Select
F1: General Help
“¤
«‹
:Select Screen
:Select Item
F2: Previous Values
F3: Optimized Defaults
ESC: Exit
F4: Save & Exit
