Chapter 3
H77H2-M4 USER MANUAL
56
CSM parameters
Scroll to this item and press <Enter> to view the following screen.
Launch CSM (Always)
This option controls if CSM will be launched.
Launch PXE OpROM policy (Do not Launch)
This controls the execution of UEFI and Legacy PXE OpROM.
Launch Storage OpROM policy (Legacy only)
This controls the execution of UEFI and Legacy Storage OpROM.
Launch Video OpROM policy (Legacy only)
This controls the execution of UEFI and Legacy Video OpROM.
Other PCI device ROM priority (Legacy OpROM)
For PCI devices other than Network, Mass storage or Video defines which OpROM to
launch.
Boot option filter (UEFI and Legacy)
This option controls what devices system can boot to.
Main Advanced Chipset M.I.B III Boot Security Save &Exit
Launch CSM Always
Boot option filter UEFI and Legacy
Launch PXE OpROM policy Do not launch
Launch Storage OpROM policy Legacy only
Launch Video OpROM policy Legacy only
Other PCI device ROM priority Legacy OpROM
This option controls if CSM
will be launched
Hard Disk Drive/ CD/DVD ROM Drive/ USB/IDE Floppy Drive/ USB CD/DVD ROM Drive/
USB HardDisk Drive/ USB Flash Drive/ NETWORK Device Drive Priorities
These items enable you to specify the sequence of loading the operating system.
Press <Enter> to see the submenu.
CSM parameters
OpROM execution, boot options filter,etc.
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
To Next Page
