Chapter 1
2
KAM1-I USER MANUAL
CPU
Specifications
• Single-channel DDR3 memory architecture
• 2 x 240-pin DDR3 Long DIMM sockets support up to 32 GB
• Supports DDR3 1600/1333 MHz DDR3 SDRAM
Memory
• 1 x PCI Express x16 Gen2 slot (runs at X4 mode)
• 1 x Mini PCI Express x1 slot (half card, supports WIFI only)
Expansion
Slots
Storage
• 1 x PS/2 Combo
• 4 x USB 2.0 ports
• 1 x COM port
• 1 x HDMI (or DVI) port
• 1 x VGA port
• 2 x USB 3.0 ports
• 1 x RJ45 LAN connector
• 1 x Audio port (Line in, Line out, Mic_in Rear)
Rear Panel I/O
LAN
• AMD AM1 Socket
Note: This motherboard delieverys without CPU, we recommand
to use AMD Athlon and Sempron Processors. Please go to ECS
website for the latest CPU support list.
Note: Please go to ECS website for the latest Memory support list.
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin CPU_FAN header
• 1 x 4-pin SYS_FAN header
• 1 x USB 2.0 header supports additional two USB 2.0 ports
• 2 x SATA 6Gb/s connectors
• 1 x COM header
• 1 x Case open header
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
• 1 x Parallel port header(LPT)
• 1 x CLR_CMOS header
• 1 x SPDIF out header
• 1 x LPT header
• 1 x BZ header
• 1 x LDC header
• 1 x VGA header (optional)
Internal I/O
Connectors &
Headers
Audio
• 2 x Serial ATA 6.0 Gb/s Host Controllers
• Realtek ALC662-VD0-GR 48P 6-ch High Definition audio CODEC
• Compliant with HD audio specification
• Realtek RTL8111G Gigabit LAN
To Next Page
