Chapter 3
NM70-I USER MANUAL
34
ESC/Right Click: Exit
F4: Save & Exit
SATA Configuration
Use this item to show the mode of serial SATA configuration options.
SATA Mode (IDE Mode)
Use this it
em to select SATA mode.
SATA Port1~4 (Empty)
This motherboard supports four SATA channels, each channel allows one SATA device
to be installed. Use these items to configure each device on the SATA channel.
Press <Esc> to return to the Advanced Menu page.
Main Advanced Chipset Tweak Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Determines how SATA
controller(s) operate.
SATA Configuration
SATA Mode IDE Mode
SATA Port1 Empty
SATA Port2 Empty
SATA Port3 Empty
SATA Port4 Empty
