Using BIOS
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Help Item
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
PC Health Status
: Move F10: Save ESC: Exit
+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
mnlk
Smart Fan Function (Press Enter)
f
Scroll to this item and press <Enter> to view the following screen:
SMART Fan Control (Enabled)
This item allows you to enable/disable the control of the CPU fan speed by changing
the fan voltage.
-=- System Hardware Monitor-=-
Smart Fan Function Press Enter
System Temperature 26°C/78°F
CPU Fan Speed: 778RPM
System Fan Speed: N/A
CPU Vcore: 1.152V
VDIMM: 1.104V
-=- PECI Mode-=-
Offset to TCC Activation Temp.: -59
Case Open Warning Disabled
Chassis Opened Yes
f
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
Smart Fan Function
Help Item
Options
mnlk
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Load Default Settings
F1: General Help
Smart Fan Control Enabled
SMART Fan Mode Normal
SMART Fan start PWM value 28
SMART Fan start PWM TEMP 32
DeltaT +3
SMART Fan Slope PWM value 4
Fan1 Full Speed Offset (-) 7
SYS SMART FAN Control DIsabled
Disabled
Enabled
