EDI CMUip-2212-HV User Manual

CMUip-2212 Cabinet Monitor Unit
Operations Manual
Eberle Design Inc. Page 24
Fault ......................................................................................... greater than 1500 ms
No Fault ......................................................................................... less than 1200 ms
Typical .......................................................................................................... 1350 ms
Yellow Clearance
Fault .............................................................................................. less than 2600 ms
No Fault .................................................................................... greater than 2800 ms
Typical .......................................................................................................... 2700 ms
Yellow Plus Red Clearance
Fault .............................................................................................. less than 2600 ms
No Fault .................................................................................... greater than 2800 ms
Typical .......................................................................................................... 2700 ms
Field Check
Fault ......................................................................................... greater than 1600 ms
No Fault ......................................................................................... less than 1400 ms
Typical .......................................................................................................... 1500 ms
Local Flash Status
Fault ........................................................................................... greater than 350 ms
No Fault ........................................................................................... less than 200 ms
Typical ............................................................................................................ 300 ms
Circuit Breaker Trip
Fault ........................................................................................... greater than 400 ms
No Fault ........................................................................................... less than 200 ms
Typical ............................................................................................................ 350 ms
AC Line Level Sense
Fault ........................................................................................... greater than 750 ms
No Fault ........................................................................................... less than 550 ms
Typical ............................................................................................................ 650 ms
Flasher (HDFU) Alarm
Active ........................................................................................ greater than 2500 ms
NRESET, POWERDOWN
Active .......................................................................................... greater than 120 ms
Not Active .......................................................................................... less than 80 ms
Typical ............................................................................................................ 100 ms
FYA Flash Rate
No Fault ................................................................................ less than 1300 msec
Fault ................................................................................ greater than 1500 msec
Typical ................................................................................................. 1450 msec
5.3 MECHANICAL
Height ............................................................................................................... 4.166 inches
Width ................................................................................................................ 2.340 inches
Depth (front panel to rear edge of DIN connector) ............................................ 7.682 inches
5.4 ENVIRONMENTAL
Storage Temperature Range ........................................................................... -45 to +85
o
C
Operating Temperature Range ........................................................................ -34 to +74
o
C
Humidity (non-condensing) ....................................................................... 0 to 95% Relative
