8460
ENGINE:
Displacement: 2.79 cu. in (45.7 cc)
Bore: 1.65 in (42 mm)
Stroke: 1.30 in (33 mm)
PERFORMANCE:
Idle Speed: 2,500 ÷ 2,800 RPM
WOT (With Blade): 10,500 ± 300 RPM
Power: 2.5 hp/1.8 kW (7,500 RPM)
8460 and 8530
FUEL AND OIL SYSTEMS:
Carburetor: Multi Position Diaphragm Carburetor
Fuel Tank Capacity: 47.3 oz. (1,400 ml)
Fuel Mix: See Operation-Fueling Section
IGNITION SYSTEM:
Spark Plug: NGK BPMR7A
Spark Plug Gap: 0.02 in. (0.5 mm)
STORAGE
TECHNICAL DATA
WARNING: Stop engine and allow to cool, and secure the unit before storing or transporting in
a vehicle. Store unit and fuel in an area where fuel vapors cannot reach sparks or open flames
from water heaters, electric motors or switches, furnaces, etc. Store unit with all guards in place.
Position so that any sharp object cannot accidentally cause injury to passersby. Store the unit
out of reach of children and other unauthorized persons.
1. Drain and clean the fuel tank in a well ventilated area.
2. Drain all fuel from tank into a container approved for gasoline. Run engine until it stops. This will remove all
fuel-oil mix which could become stale and leave varnish and gum in the fuel system.
3. Clean all foreign material from the brush cutter. Keep away from corrosive agents such as garden chemicals
and de-icing salts.
4. Abide by all Federal and local regulations for the safe storage and handling of gasoline. Excess fuel should
be used in other 2-cycle engine powered equipment.
CAUTION: It is important to prevent gum deposits from forming in essential fuel system parts
such as the carburetor, fuel filter, fuel hose, or fuel tank during storage. Alcohol blended fuels
(called gasohol or E10 or using ethanol, methanol) can attract moisture which leads to fuel
mixture separation and formation of acids during storage. Acidic gas can damage the engine.
8530
ENGINE:
Displacement: 3.21 cu. in (52.5 cc)
Bore: 1.77 in (45 mm)
Stroke: 1.30 in (33 mm)
PERFORMANCE:
Idle Speed: 2,500 ÷ 2,800 RPM
WOT (With Blade): 10,500 ± 300 RPM
Power: 2.8 hp/2.1 kW (7,500 RPM)
32
en
