EINHELL TC-AG 18/115 Li-Solo User Manual

GB
- 21 -
Tool side Suitable for
Left (position A / as
shown)
Right-handed users
Right (position B) Left-handed users
Top (position C) Using cutting wheels
5.2 Replacing and adjusting the guard (Fig. 3)
Replacing:
•
Remove the flange nut (b) and the clamping
flange underneath.
•
Undo the screw (a) on the guard (4).
•
Turn the guard (4) through 180° in clockwise
direction so that the guard points upwards.
•
Remove the guard (4).
To mount, proceed in the reverse order.
Adjusting:
•
Adjust the guard (4) to protect your hands
so that the material being ground is directed
away from your body.
•
The position of the guard (4) can be adjusted
to any specific working conditions. Undo the
screw (a) and turn the cover (4) into the requi-
red position.
•
Ensure that the guard (4) correctly covers the
gear wheel casing.
•
Retighten the screw (a).
•
Ensure that the guard (4) is secure.
Make sure that the guard is perfectly secure.
Never use the angle grinder without the gu-
ard.
5.3 Test run for new grinding Wheels
Allow the right-angle grinder to run in idle for at
least 1 minute with the grinding or cutting wheel
fi tted in place. Vibrating wheels are to be replaced
immediately.
6. Operation
6.1 Charging the Li battery pack (Fig. 1a-1b)
1. Remove the battery pack (6) from the handle,
pressing the pushlock button (8) downwards
to do so.
2. Check that your mains voltage is the same as
that marked on the rating plate of the battery
charger. Insert the power plug of the charger
(7) into the mains socket outlet. The green
LED will then begin to fl ash.
3. Push the battery pack onto the battery char-
ger.
In section 10 (Charger indicator) you will fi nd a
table with an explanation of the LED indicator on
the charger.
If the battery pack fails to charge, check for the
following:
•
voltage at the power socket
•
whether there is good contact at the charging
contacts of the charging unit
If the battery pack still fails to charge, send
•
the charger and charging adapter
•
and the battery pack
to our customer service center.
To ensure that the Li battery pack provides
long service you should take care to recharge
it promptly. You must recharge the battery pack
when you notice that the power of the cordless
equipment drops.
6.2 Switch (Fig. 4)
The angle grinder comes with a safety switch
which is designed to prevent accidents. To switch
on, push the On/Off switch (2) to the right and
then forwards. To switch off the angle grinder,
depress the On/Off switch (2) at the back. The
On/Off switch (2) will jump back into its starting
position.
Wait until the machine has reached its top
speed. You can then position the angle grin-
der on the workpiece and machine it.
Anl_TC_AG_18_115_Li_Solo_SPK9.indb 21Anl_TC_AG_18_115_Li_Solo_SPK9.indb 21 26.09.2017 10:31:0026.09.2017 10:31:00

EINHELL TC-AG 18/115 Li-Solo Specifications

General

Product color	Black, Red
Adjustable speed	Yes
Number of handle positions	3
Idle speed (max)	8500 RPM
Cutting depth (max)	28 mm
Grinding disc diameter	115 mm
Power source	Battery
Battery included	No

Weight and Dimensions

Weight	1210 g
Package depth	142 mm
Package width	290 mm
Package height	108 mm
Package weight	2180 g
