Network Port RJ-45 (USB LAN Adapter)
Supported OS Microsoft Windows 10 (32-bit/64-bit)
Microsoft Windows 8.1 (32-bit/64-bit)
macOS Sierra (10.12) or later
Wired LAN IEEE802.3ab (1000BASE-T), IEEE802.3u (100BASE-TX),
IEEE802.3 (10BASE-T)
Power Input 100 - 240 VAC ±10 %, 50 / 60 Hz 1.60 A - 0.70 A
Maximum Power
Consumption
155 W or less
Power Save Mode 0.5 W or less (no USB device connected, “USB” in the “Administrator
Settings” menu: O)
Standby Mode 0.5 W or less (no USB device connected, default settings)
Physical
Specications
Dimensions 537.8 mm × 344.7 mm to 539.7 mm × 230.0 mm to 258.0 mm (W × H × D)
(Tilt: 35˚)
537.8 mm × 332.4 mm to 523.6 mm × 230.0 mm (W × H × D) (Tilt: 0˚)
Dimensions
(Without Stand)
537.8 mm × 320.4 mm × 57.4 mm (W × H × D)
Net Weight Approx. 7.2 kg
Net Weight
(Without Stand)
Approx. 4.5 kg
Height Adjustment
Range
195.0 mm (Tilt: 35˚) / 191.2 mm (Tilt: 0˚)
Tilt Up 35˚, down 5˚
Swivel 344˚
Vertical Rotation Left 90˚, right 90˚
Operating
Environmental
Requirements
Temperature 5 ˚C to 35 ˚C
Humidity 20 % to 80 % R.H. (no condensation)
Air Pressure 540 hPa to 1060 hPa
Transportation /
Storage
Environmental
Requirements
Temperature -20 ˚C to 60 ˚C
Humidity 10 % to 90 % R.H. (no condensation)
Air Pressure 200 hPa to 1060 hPa
*1 HDMI CEC (or mutual control) is not supported.
*2 Supports Pin Assignment E. Commercially available converter cables (USB-C - DisplayPort) can be connected
to the DisplayPort connector of the PC.
*3 Supports daisy chains with DisplayPort Alt Mode.
*4 It is possible to supply power even if the PC and the monitor are not connected by USB.
●
Accessories
For the latest information about accessories, refer to our web site www.eizoglobal.com.
40
Chapter 7 Reference
